一、Product Overview：

The KODIN 9 series FM pipeline anti-corrosion layer detector can locate target pipelines in densely populated areas.
The operator can measure the magnitude and direction of the signal current applied by the system transmitter, and the receiver performs necessary calculations to obtain the calculation results through measurement. It is possible to accurately locate defect points without excavating the anti-corrosion layer.
The KODIN 9 series FM pipeline anti-corrosion layer detector is equipped with an Android system and can obtain measurement parameters in the system's built-in app. When connected to WIFI, real-time drawing, surveying, and detection results can also be directly shared on mobile phones or computers.

二、Performance Parameters：

Matching transmitter model: S80
Transmitter frequency: 4Hz+128Hz, 4Hz+8Hz+128Hz, 4Hz+8Hz+640Hz, 1kHz
Transmitter power supply: built-in 33.6V 10.4Ah lithium battery+external DC power supply (optional)
Detection distance: 15km
Transmitter power: 80W
Detection depth: 15 meters
Transmitter output current: 100mA, 200mA, 400mA, 600mA, 800mA, 1A
GNSS satellite positioning accuracy: RTK centimeter level
Positioning coordinate format conversion: support
Integrated detection and surveying: support
Real time point distance: supported
Data Storage: Supports
Customized APP: Supports
Export data: Excel, Word, ZIP
Transmitter connection output method: direct connection
Receiver receiving frequencies: F1 (4Hz+128Hz), F2 (4Hz+8Hz+128Hz), F3 (4Hz+8Hz+640Hz), 128Hz, 512Hz, 1kHz
Pipeline positioning accuracy: ± 5% of depth (0-3m)
Depth measurement accuracy: ± 5%
Current measurement accuracy: ± 5%
Leakage point positioning accuracy: ± 10cm
A-frame: standard configuration
Receiver display screen: 4-inch IPS touch high-definition LCD screen
Data interface: wireless communication and USB interface
Storage method: 16GB eMMC, expandable 32GB TF card
Usage environment: Relative humidity: ≤ 90%; Temperature: -10 ℃ to+40 ℃
Receiver battery: 3.7V 12000mAh lithium battery
Receiver working time: Receiver: 10-20 hours

三、Site of use：

四、Standard product packing list：

1. KODIN 9B-FM Receiver 1
2. KODIN 9B-FM/S80 transmitter 1
3. A-frame (with A-frame connecting wire) 1
4. KODIN 9 Series FM Receiver Handbag 1
5. 4.2V 2A power adapter 1
6. 33.6V 2.5A power adapter 1
7. DC power cord 1
8. Output Line 1
9. Micro USB data cable 1
10. Iron file 1
11. Grounding nail 2
12. Magnetic attraction 1
13. 250V5A fuse 2
14. SIM card removal needle 1
15. Portable lithium battery pack (36V15Ah)+optional charger
16. Receiver battery compartment (with battery) optional
17. Screen film optional
